True   27 1/2″ One Section Pass Thru Refrigerator, (1) Glass Door, (1) Solid Door, Right Hinge, 115v

The True STR1RPT-1S-1G-HC Spec Series® pass-thru refrigerator enables food to flow from the back to the front of house with doors on both sides. Its front door is solid and made of stainless steel, while its back door is glass. To keep heat out, these doors are lined with magnetic gaskets, and the double-pane glass is thermal insulated. Polyurethane insulation is foamed in the walls, adding structure and slowing heat transfer.

Cooled by the capillary tubes in the refrigeration system, the unit can be set between 33 and 38 degrees Fahrenheit. These cold temperatures are achieved by R290 hydrocarbon refrigerant flowing through the tubes. To minimize heat produced by the system, evaporator and condenser fans ensure consistent airflow. The temperature can be found on the exterior’s digital display and can be set to read in Fahrenheit or Celsius.

When this unit’s compressor is turned on, its fan motor blows air in an opposite direction to reduce buildup of dust, dirt, and debris on the condensing coil. With daily removal, the coil can operate more efficiently for longer periods without using as much energy. This feature should not replace preventative maintenance practices.

Inside the True STR1RPT-1S-1G-HC pass-thru refrigerator, adjustable shelves support contents. Each shelf is chrome plated for sturdiness with a wire design for improved airflow. For visibility, LED lights shine on products while bolt locks on the doors provide security. Although the doors self-close to keep cold air trapped inside, they stay open past 120 degrees for loading and unloading. Castors enable staff to move the refrigerator to clean underneath, and the door gaskets can be removed for cleaning.

Product Details

• Part of the Spec Series
• Stainless steel construction is scratch and corrosion resistant
• Dense polyurethane insulation keeps cold air in
• Comes with 3 chrome-plated wire shelves
• LED lights shine on stored items
• Digital display shows temperature in Celsius or Fahrenheit
• 4 castors enable movement
• Front pair of castors lock to keep unit stationary

Pass-thru Doors

• Doors on front and back provide interior access from either side
• Front door is solid
• Back door is glass
• Glass keeps heat out since it is double paned and thermal insulated
• Handles are constructed of metal for durability
• Bolt locks limit access
• Self-close if opened less than 120 degrees
• 120-degree, stay-open feature facilitates loading and unloading
• Magnetic gaskets prevent air leaks
• Gaskets have a removable, single-piece construction

Refrigeration System

• Temperature holding range: 33-38 degrees F
• Cools using R290 hydrocarbon refrigerant in its capillary tubes
• Evaporator and condenser fan motors consistently circulate air and reduce energy use
• Reverse condensing fan motor helps eliminate condensing coil buildup
• Evaporator’s epoxy coating wards off rust
• Self-contained to support maintenance
• Top mounted to reduce tampering risks
