Hoshizaki DCM-271BAH-OS Description
The Hoshizaki DCM-271BAH-OS touchless ice and water dispenser produces 257 pounds of Cubelet-style ice once a day; its built-in storage can hold 10 pounds of ice at one time. Because this unit features a self-contained refrigeration system, it’s simple to install, and it operates with R-404A refrigerant. Designed for countertop installation, this dispenser sits on 4-inch legs.
Overall, the Hoshizaki DCM-271BAH-OS touchless countertop ice and water dispenser measures 165/8 inches wide by 241/4 inches deep by 313/4 inches high. To accommodate various drinkware, this ice machine has a 101/4-inch cup clearance. It features a CleanCycle24™ design to simplify cleaning processes and is protected with an H-GUARD PLUS® antimicrobial agent to slow bacterial growth between regular cleanings. Because this unit is constructed of stainless steel, it’s durable and corrosion resistant for long-term use; to maintain cleanliness during hours, it has a 2-second flush cycle.
Product Details
- Produces 257 lbs. every 24 hours
- 10-lb. built-in storage capacity
- Cubelet-style ice cubes
- Cube dimensions: 1⁄4 in. min L x 5/8 in. max L x 3/8 in. W x 1⁄2 in. H
- 101/4-in. cup clearance
- Countertop model
- Touchless LED sensor
- Stainless steel construction
- Drain pan grate
- Removable spout
- H-GUARD Plus antimicrobial agent
- Advanced CleanCycle24™ design
- 2-second flush cycle per hour
- 4-in. legs
- Air cooled, self-contained condenser
- R-404A refrigerant
- 3,300 BTU
- Ambient temperature range: 45-100 degrees F
- Water temperature range: 45-90 degrees F
- Pressure range: 10-113 PSIG
Dimensions & Utilities
- 165/8 in. W x 241/4 in. D x 313/4 in. H
- 8.5 A, 6.9 kW
- 115 V/60 Hz/ 1 ph with 6-ft. cord and NEMA 5-15P plug
- 3⁄4 in. MPT drain connection
- 1⁄2 in. FPT supply connection
Hoshizaki DCM-271BAH-OS Specifications
| Spec Attribute | Spec Value |
|---|---|
| Manufacturer | Hoshizaki |
| 24 Hr. Production (lb) | 257 |
| Amps | 8.5 |
| Bin Capacity (lb) | 10 |
| Compressor Type | Air Cooled |
| Depth (in) | 24.25 |
| Height (in) | 31.75 |
| Hertz | 60 |
| Ice Type | Nugget |
| Operation | Self Contained |
| Serving Vessel | Cup |
| Special Features | LED Sensor Operation |
| Voltage | 115 |
| Warranty | 3-year Parts & Labor; 5-year Compressor & Condenser Parts |
| Width (in) | 16.63 |
| Series | Opti-Serve |
| Phase | 1 |
| Rating | Best |
| Product | Ice Dispensers |
| Product Type | Ice Makers & Bins |
| Dispenser Type | Sensor |
| Dispenses | Ice & Water |
| NEMA | 5-15P |
| Installation Type | Countertop |
| Weight | 154.00 |
Additional information
| Weight | 154 lbs |
|---|---|
| Dimensions | 16.63 × 24.25 × 31.75 in |
