Description
Refrigeration System
? Bottom mounted, self-contained and fully detachable Blizzard R290 condensing unit uses
environmentally friendly, EPA-compliant R290 refrigerant with zero (0) Ozone Depletion
Potential (ODP) and three (3) Global Warming Potential (GWP). Blizzard R290 is easily
replaceable and requires no on-site brazing.
? Electronically commutated (ECM) fan motors achieve rapid cooling with less energy
consumption.
? Full-length air duct ensures optimal cold air distribution (except EMGR5(B).
? Air circulation guard keeps floor vents from obstruction (except EMGR5(B).
? Time-initiated and temperature-terminated auto defrost cycle for seamless operation.
? Large capacity, corrosion-resistant condenser and evaporator coils.
? Self-maintaining, energy-efficient condensate drain pan requires no external drains or
electric heaters.
? High performance, auto-reverse condenser fan motor supports compressor ventilation and
condenser coil cleaning.
? Pre-wired and ready to plug, 115V/60Hz/1Ph, NEMA 5-15P.
Cabinet Construction
? White coated steel exterior/interior.
? Stainless steel floor interior has rounded corners and detachable drain plug for ease of
cleaning.
? 2.5″ thick high density polyurethane insulation.
? Four height adjustable screw legs.
Lighting
? Shielded LED bar lighting with on/off switch provides bright, high color illumination at lower
heat output.
Doors
? Low emissivity double glass panes reflect UV rays for efficient cooling.
? Black PVC door frames.
? Self-closing with adjustable torsion system for a positive seal.
? Snap-in magnetic door gasket make cleaning and replacement an easy process.
? High strength, die-cast door handles.
Shelving
? Epoxy coated, steel wire shelves with airflow guard (see table for quantity).
? Height adjustable stainless steel clips.
Temperature Control
? Multi-function digital controller with easy to read LED display.
? Factory preset temperature, 35?F. Temperature setting range from 33?F to 54?F.
? Audible overheat protection alarm for compressor and condenser coil.
Options
? Additional shelving.
? 5? or 3? swivel casters with locks on front set.
? 3.5? ? 6? height-adjustable and interchangeable legs.
? NAMA certified, NSF compliant Health Timer Lock
Refrigerant HP
Power
V-Hz-Ph Amps
| Brand | Everest Refrigeration |
|---|---|
| Model Number | EMGR20B |
| Weight | 314 lbs |
| Width | 24.75″ |
| Depth | 30.75″ |
| Height | 79.75″ |
| Size | 1 section |
| Door Style | swing |
| Refrigeration | self-contained, bottom mounted |
| Exterior Finish | black |
| Capacity (cu. ft.) | 20 |
| Compressor HP | 1/4 HP |
| Certifications | cETLus, ETL-Sanitation, NSF |
Additional information
| Weight | 314 lbs |
|---|---|
| Dimensions | 24.75 × 30.75 × 79.75 in |
